Gens ace 20C 2600mAh 6s 22.2v Li-Po Battery

ACE20-2600-0601

Click to enlarge image

Gens ace 20C lithium polymer battery. With JST-XH type balance plug. Generally considered to be under-rated, Gens Ace lithium polymer batteries combine superb performance and durability, with quality pack construction. All Gens Ace batteries feature a standard balance connector and pre-tinned cables for fast soldering.

The Gens Ace 2600mAh 6s (22.2V nominal) Li-Po battery is a good choice for the Trex 500 and similar helicopters.

Specification for Gens ace 20C 2600mAh 6s 22.2v Li-Po Battery:-

Capacity: 2600mAh
Cells: 6
Nominal Voltage: 22.2v
Balance Plug Type: JST-XH
Weight (grams): 420g
Weight (ounces): 14.70oz

Do not charge above 25.2 volts.

Please scroll down to see the full technical specification.

Batteries with similar capacity and voltage
Pack Name	mAh	Config	Volts	Weight	Price	Stock
Gens ace 20C 2600mAh 6s 22.2v Li-Po Battery (This one)	2600mAh	6S1P	22.2V	420g	$43.71
Gens ace 25C 2500mAh 6s 22.2v Li-Po Battery	2500mAh	6S1P	22.2V	430g	$49.49

Technical Details for Gens ace 20C 2600mAh 6s 22.2v Li-Po Battery

*Capacity (mAh)*	2600
Dimensions (mm)	116x31x50
Pack Configuration	6S1P
Balance Plug	Yes
Balance Plug Type	JST-XH
Continuous Discharge (C)	20.0C
Continuous Current (A)	52.0A
Burst Discharge (C)	40.0C
Burst Current (A)	104.0A
Maximum Charge Rate (C)	5.0C
Maximum Charge Rate (A)	13.0A
Discharge Plug	No
Chemistry	Li-Poly
Weight	420.0g (14.8oz.)
