The AXi Gold Line 2217/5H motor is a powerful high RPM 8 pole brushless outrunner motor with neodymium magnets and a rotating case.
This motor was designed especially for the Mini Titan heli and T-REX heli up to 800g in weight. As a result of using the latest ferromagnetic materials the AXI 2217/5H offers extremely high efficiency and high load capability for its weight.
For good cooling of the motor when used in helis with a canopy, the AXI cooler for AXI 22xx is recommended.
Other AXi motors in this series:
AXi 2217/12, AXi 2217/16, AXi 2217/20, AXi 2217/20 Droidworx Edition, AXi 2217/20 Short Shaft, AXi 2217/9D, AXi 2217/9DPG
Recommended setups for AXi 2217/5H
| Type |
Model Weight |
Cells |
Max. Current |
Jeti ESC |
Propeller |
|
| Heli |
800g (28.2oz) |
3s |
34.0A/30s |
Jeti Spin 44
|
-
|
|
Do not exceed the recommended propeller sizes.
Always use slow-fly type propellers with AXi 22xx series motors.
